BCM957412A4120AC 10GbE Dual-port SFP+, PCIe 3.0 x 8
Applications
The BCM957412A4120AC is a dual-port 10 Gb/s PCI-Express 3.0 x8 Network Interface Card that supports both SFP+ optical modules and copper direct-attach cables. It features the Broadcom BCM57412 10GbE MAC controller with an integrated dual-channel 10GbE SFI transceiver. The card is equipped with advanced technologies such as RoCE, SDN, and NFV to ensure efficient network management.
Built on the scalable BCM57412 10GbE MAC controller architecture, the P210P 2x10G PCIe NIC is engineered to deliver highly scalable and feature-rich networking solutions for servers. It is ideal for enterprise and cloud-scale networking and storage applications, including high-performance computing, telecommunications, machine learning, storage disaggregation, and data analytics.
Key Features
- The dual-port pluggable media interface supports both 10G SFP+ optical transceivers and copper direct-attach cables.
- It is fully compliant with the SFF-8402 standard and adheres to the x8 PCI Express v3.0 specification.
- The interface features SR-IOV with support for up to 128 virtual functions (VFs) and includes Function Level Reset (FLR) capability.
- It enables virtual network termination for protocols such as VXLAN, NVGRE, and GRE encapsulation/decapsulation, along with vSwitch acceleration.
- Additionally, it provides tunnel-aware stateless offloads and supports RDMA over Converged Ethernet (RoCE).
- The interface also complies with the SMBus 2.0 standard.
Specification
| Model |
BCM957412A4120AC |
| Data Rate Per Port |
10/1GbE |
| Connector Type |
SFP+ |
| Bracket Height |
Full Height and Low Profile |
| Controller |
BCM57412 |
| Systems Interface Type |
PCIe 3.0x 8(8.0 GT/s) |
Lead time
| Quantity (pieces) |
1-10 |
10-60 |
>60 |
| Lead time (days) |
3 |
3-5 |
To be negotiated |
