■ Complete kit package includes necessary cables and brackets
■ Includes JBOD Mode support Applications
■ Internal storage configurations
■ 1U/2U rack servers
■ File, Web, database and email servers
■ High-performance workstations
Typical Uses
■ Direct-attach, internal SAS or SATA hard disk drives (HDDs) and solid state drives (SSDs)
■ High volume, “warm data” access
Key Features
■ Eight internal 12Gb/s SATA+SAS ports
■ x8 PCI Express 3.0 host interface
■ Two x4 SFF-8643 mini-SAS HD internal connectors
■ LSISAS3008 PowerPC 476 controller @ 1.2GHz
■ RAID 0, 1, 5, 10, 50 and JBOD mode
■ Low-profile form factor
■ Supports up to 64 devices in JBOD mode
■ Up to 32 physical devices in RAID mode
■ Powerful device monitoring and maintenance capabilities
Specification
Model
LSl 9340-8i
Ports
8 Ports int
Connectors
One mini-SAS SFF8643 internal connectors
Data Transfer Rates
Up to 12 Gb/s per port
Host Bus Type
8-lane, 5 GT/s PCI Express 3.0 Compliant
l/0 Processor/SAS Controller
LSI SAS3008
Key RAID Data Protection Features
RAID levels 0, 1, 5, 10, 50 and JBOD mode
Brackets
Full Height and Low-Profile
Warranty
3 years
Availability
In Stock
